Built for the Aquaculture Industry

KingYoung provides you field-verified wireless IoT system for data acquisition and automation on aquacultural application.

Sensor nodes were designed to survive the harsh environment factors such as sun exposure, wind, rain, and salt mist.

Learn More

Highly Integrated Cloud Platform

KingYoung IoT solutions is highly integrated with cloud platform. All devices is connected with the cloud and can be monitored through the Internet

Collected sensor data is stored in the cloud and can be browsed through anytime.

Easy Environmental Controlling

Environmental controlling could be configured on your own smart phone, and could be adjusted anytime when needed.

System can automatically execute pre-configured actions when certain pre-configured conditions are met. (e.g. turn on the aerator when the dissolved oxygen level is too low.)

Easy Deployment and Maintenance

The cord-less design greatly simplified the deployment process, and eliminated the cost for cable installation and maintenance.

Specially designed sensors can be cleaned and maintained on site with ease.

Extensible and Customizable

KingYoung IoT solution is built with various function modules, which means the system can be extended and customized with your requirement. Check the link below to see the available modules for customization.

Find by target application

Modules

  • IC-120 PhotoIC-1202 Channel Current Sensor with Dry Contact Output
    • Early mechanical failure detection with near real-time current monitoring.
    • Capable of remote controlling motors / equipments with external contactors.
    • Cord-free deployment with mesh-based wireless network.
    • Easy installation with clamp type CT.
    More Details
  • IC-121 PhotoIC-1212 Channel Current Sensor with 3A AC Output
    • Early mechanical failure detection with near real-time current monitoring.
    • Capable of remote controlling motors / equipments with external contactors.
    • Capable of powering low power devices such as buzzers or alarms.
    • Cord-free deployment with mesh-based wireless network.
    • Easy installation with clamp type CT.
    More Details
  • IC-131 PhotoIC-1314 Channels Dry Contact Output
    • 4 channels dry contact output.
    • Capable of remote controlling motors / equipments with external contactors.
    • Cord-free deployment with mesh-based wireless network.
    • Easy installation to the DIN 35mm Rail.
    More Details
  • IC-151 PhotoIC-1512 Channel Voltage/Current Sensor with 8A AC Output and 1 Dry Contact Output
    • Input power rating: AC 3-phase 220V.
    • Output power rating: AC 3-phase 220V 8A (2 hp).
    • Early mechanical failure detection with near real-time current and voltage monitoring.
    • Capable of remote controlling motor / equipment directly.
    • Cord-free deployment with mesh-based wireless network.
    • IC-152 can be connected by dry contact for controlling the second motor / equipment.
    More Details
  • IC-152 PhotoIC-1528A AC Output and 1 Dry Contact Input
    • Input power rating: AC 3-phase 220V.
    • Output power rating: AC 3-phase 220V 8A (2 hp).
    • Capable of controlling motor / equipment directly.
    • Can be connected to IC-151 by dry contact for controlling the second motor / equipment.
    More Details
  • IC-161 PhotoIC-1612 Channel Voltage/Current Sensor and an AC Output
    • Input power rating: AC 1-phase 110V or 3-phase 220V.
    • Output power rating: AC 1-phase 110V or 3-phase 220V.
    • Early mechanical failure detection with near real-time current and voltage monitoring.
    • Capable of remote controlling motor / equipment directly.
    • Cord-free deployment with mesh-based wireless network.
    More Details
  • IC-181A PhotoIC-181A2 Channel Voltage/Current Sensor 2 Dry Contact Output
    • Input power rating: AC 3-phase 220V.
    • 2 channels dry contact output.
    • Capable of remote controlling motors / equipments with external contactors.
    • Early mechanical failure detection with near real-time current and voltage monitoring.
    • Capable of remote controlling motor / equipment directly.
    • Cord-free deployment with mesh-based wireless network.
    More Details
  • IDE-100 PhotoIDE-100DO + EC Sensor (seawater model)
    • Real-time unattended DO, EC, salinity and temperature monitoring.
    • Automatic temperature and salinity compensation for DO.
    • Automatic temperature compensation for salinity.
    • Easy installation with cord-free design.
    • Water-proof and weather-resistant design.
    • Simplified deployment with Smart Buoy Technology.
    More Details
  • IDE-101 PhotoIDE-101DO + EC Sensor (freshwater model)
    • Real-time unattended DO, EC and temperature monitoring.
    • Automatic temperature compensation for DO.
    • Easy installation with cord-free design.
    • Water-proof and weather-resistant design.
    • Simplified deployment with Smart Buoy Technology.
    More Details
  • IDE-102 PhotoIDE-102DO + EC Sensor (freshwater model)
    • Real-time unattended DO, EC and temperature monitoring.
    • Automatic temperature compensation for DO.
    • Easy installation with cord-free design.
    • Water-proof and weather-resistant design.
    • Simplified deployment with Smart Buoy Technology.
    More Details
  • IMB-100 PhotoIMB-100Multi-protocol integration module - EIA-485(RS-485)
    • Powered through convenient and safe DC 5-12V.
    • Integrate numerous types of existing sensors and devices into the IoT system through EIA-485(RS-485).
    • Cord-free deployment with mesh-based wireless network.
    More Details
  • IO-100 PhotoIO-100ORP Monitoring Sensor
    • Real-time unattended ORP monitoring.
    • Easy installation with cord-free design.
    • Water-proof and weather-resistant design.
    • Simplified deployment with Smart Buoy Technology.
    More Details
  • IP-100 PhotoIP-100pH Monitoring Sensor
    • Real-time unattended pH monitoring.
    • Automatic temperature compensation for pH.
    • Easy installation with cord-free design.
    • Water-proof and weather-resistant design.
    • Simplified deployment with Smart Buoy Technology.
    More Details
  • IR-132 PhotoIR-132IoT Smart Gateway
    • Connects up to 32 KingYoung IoT devices through mesh wireless network.
    • Internal battery for at least 4 hours of backup operation.
    • Wifi for connecting to the cloud platform.
    • Optional LTE(4G) connectivity.
    • Water-resistant and weather-resistant design.
    More Details
